The Deets
Theatre Specifications
LESEDI THEATRE @ Joburg Theatre
Control
Strand 520i console.
Dimmers
10 x 5kw dimmers
74 x 2,5kw dimmers
Lanterns
16 x adb dn101 1.2 kw zoom profile (12 – 20)
20 x adb dw101 1.2 kw zoom profile (30 – 45)
10 x adb ds 101 1.2 kw zoom profile ( 18 – 38)
24 x adb f101 1.2 kw fresnel (12 – 58)
12 x adb c1o3 1.2 kw pebble convex (6 – 6o)
10 x rse patt750 1kw beam
projector
2 x adb 1.2 kw follow spot
15 led parcans
4 x moon flowers
2 x zr20 smoke machines
1 x le maitre haze/smoke machine
1 x jem techno fog smoke machine
8 x svobodas
6 x birdies
12 x 40w uv tubes
4 x mirror balls
4 x uv boosters
FOH PA system
6 x turbosound tcs 612 (2 x flown per side,
2 x center cluster)
2 x turbosound tse 215 subs (1 x per side placed on deck)
1 x c-audio ra 3001 amplifier (driving left & right highs)
1 x c-audio sr 606 amplifier (driving left & right mids)
1 x c-audio sr 606 amplifier (driving centr cluster highs & mids)
1 x c-audio sr 707 amplifier (driving subs)
2 x bss omnidrive fds 388 speaker management processor cabling for the above
FOH control
1 x behringer x32 digital console with on-board fx/processors
1 x stanton c 502 dual cd, mp3, cd-r player cabling for the above
Monitor system
4 x turbosound tmi 212 12” low profile monitor wedges
2 x crown k 1 to drive the above
2 x turbosound tcs 612 & stands on request if available (side fills)
1 x c-audio st 601 to drive the above
1 x turbosound lms 660 speaker management processor cabling for the above
Cabling & reticulation
1 x behringer s16: 16 ch input, 8 ch output digital stage box
1 x analogue 16 ch multicore cable 16 mic lines & 8 sends
1 x link through to foyer system
1 x paging link to dressing room (4 x)
1 x ring com system (lighting, stage, backstage, sound)
Comms
4 x prosound comm packs with single cup headsets
Radio mics
6 x sennheiser sk 50 uhf beltpacks using mk ii e capsules & em 1026 receiver & active wide band antenna splitter with 2 sra 1 uhf directional antennas
4 x shure pg 58 hand held transmitters mic stands for the above
Pianos
Bosendorfer 9 ft grand – black
Upright rehearsal pianos
Curtains
Set black velvet surround
Use of projectors
Please bring your own projectors and lap tops for special effects. You can discuss what you need at your rehearsal and the Joburg theatre staff will do all they can to assist you. The theatre specs remain the same as they were when we moved into to the Joburg Lesedi Theatre in 2015. Anna Ledwaba, our brilliant Stage Manager and the rest of her team, will be happy to advise you at your tech rehearsal. Two staff work with the schools in sound and lighting during your one and a half hour rehearsal.
